The Sinotruk 6 Wheeler Dump Truck is engineered for construction sites, mining operations and large-scale infrastructure projects. With a robust 6×4 chassis, this dump truck delivers outstanding payload capacity and stability. For maximum durability and genuine performance, always choose authentic sinotruk howo parts to keep your fleet running efficiently. The Sinotruk 6 Wheeler Dump Truck combines a powerful engine, heavy-duty hydraulic system, and reinforced dump body to handle gravel, sand, and demolition waste with ease.
Built Tough: Sinotruk 6 Wheeler Dump Truck Performance
The Sinotruk 6 Wheeler Dump Truck features a high-strength ladder frame chassis and a front multi-leaf suspension combined with heavy-duty rear bogie. Its dumping angle reaches up to 48 degrees, ensuring rapid material discharge even with sticky clay. Equipped with a reliable WD615 or WP10 series engine, this truck generates up to 340 HP and peak torque of 1350 Nm, enabling smooth climbing on rugged terrain. The hydraulic system uses a single or double telescopic cylinder with a PTO-driven pump, providing stable lifting force under full loads.
Every Sinotruk 6 Wheeler Dump Truck undergoes rigorous testing for structural integrity. The cab offers ROPS/FOPS certification, adjustable seats, and air conditioning for driver comfort. Additionally, the braking system integrates full air brakes with an exhaust brake, ensuring safe stopping even on steep downhill stretches. The dump body is made from high-tensile steel with reinforced ribs, resisting deformation from heavy rocks. For mining contractors, this truck reduces cycle times and increases productivity.
High-Dump Capacity: 12-18 cubic meters heaped volume, 25-ton payload on rough roads.
Fuel Efficient Engine: Euro II / III compliant, low consumption with 300L fuel tank for long shifts.
Reinforced Hydraulics: 160mm cylinder diameter, fast lifting time ≤ 25 seconds.
Easy Maintenance: Centralized grease points, wide-opening engine hood, global parts network.
Technical Specifications – Sinotruk 6 Wheeler Dump Truck
| Parameter | Specification |
|---|---|
| Drive Type | 6×4 (6 wheeler, rear tandem drive) |
| GVW (Gross Vehicle Weight) | 25,000 kg – 28,000 kg |
| Engine Model | WD615.69 / WP10.340E32 |
| Max Power | 340 HP @ 2200 rpm |
| Peak Torque | 1350 Nm @ 1200-1600 rpm |
| Transmission | HW19710, 10 forward + 2 reverse |
| Axle Ratio | 5.73 or 6.72 (heavy duty) |
| Tires | 11.00R20 / 12.00R20 (off-road tread) |
| Dump Body Capacity | 12 m³ (struck) / 16 m³ (heaped) |
| Hydraulic Lifting Time | ≤ 23 seconds (full raise) |
| Max Dumping Angle | 48° |
| Wheelbase | 3,200 mm + 1,350 mm |
| Fuel Tank Capacity | 300 L (standard) / 400 L optional |
Why Sinotruk 6 Wheeler Dump Truck Maximizes Your ROI
When comparing mid-size dump trucks, the Sinotruk 6 Wheeler Dump Truck offers outstanding value. Its robust drivetrain reduces downtime, and the availability of genuine sinotruk howo parts through regional distributors ensures fast repairs. The chassis is designed for easy mounting of different body types – from standard rear-dump to side-dump configurations. Additionally, the electronic system includes a 24V setup with dual batteries, making cold starts reliable in winter conditions. Many fleet owners report that the Sinotruk 6 Wheeler Dump Truck lowers cost per ton by 18% compared to older models.
Safety is also prioritized: the dual-circuit braking system with spring-loaded parking brake, engine exhaust brake, and optional ABS provide total control on slippery haul roads. The cab is sound-insulated and features an adjustable steering column, reducing operator fatigue. With a turning radius of just 8.5 meters, the truck maneuvers easily on tight job sites. For those operating in extreme heat, an optional oversized radiator and fan clutch keep temperatures under control. The Sinotruk 6 Wheeler Dump Truck has proven its worth in African mines, Middle Eastern quarries, and Southeast Asian infrastructure projects.
Real-World Applications & Durability
The Sinotruk 6 Wheeler Dump Truck is widely used for road construction, coal hauling, waste management, and agricultural earthmoving. Its high-strength dump box can withstand abrasive materials like basalt and granite. The rear suspension uses heavy-duty leaf springs with auxiliary springs, providing stability even when loaded to capacity. Furthermore, the air cleaner features a dual-stage filtration system, essential for dusty environments. Routine maintenance intervals are set at 8,000 km, with easy access to filters, drain plugs, and grease nipples.
For operators seeking reliability, the Sinotruk 6 Wheeler Dump Truck is backed by a 12-month / 50,000 km warranty on major assemblies. The truck also supports telematics readiness, allowing fleet managers to track fuel consumption, location, and maintenance alerts. When combined with genuine sinotruk howo parts, the truck’s lifecycle easily exceeds 500,000 km with proper care. This model is also customizable: choose different body thickness (6mm bottom plate, 4mm side plate) or heavy-duty rock liners.
Investing in a Sinotruk 6 Wheeler Dump Truck means investing in productivity. The powerful engine, combined with the robust 6×4 configuration, ensures you can move more material per shift. Whether you are upgrading an old fleet or expanding your construction capacity, this dump truck delivers consistent output. The hydraulic system is protected by a high-pressure relief valve and a large oil tank, preventing overheating during intensive cycles. Additionally, the cab features a digital dashboard and ergonomic controls, making operation intuitive and safe. For any heavy-haul business, the Sinotruk 6 Wheeler Dump Truck stands as a cost-effective and dependable workhorse.
